Commercial Fans & Blowers
ITEM NUMBER : BI-16RM | Commercial Fans & Blowers
The DELHI BI-RM Series Belt Drive Utility Blowers - Restaurant Model offers a complete range of sizes from 10" to 36", with full AMCA Class 1 operation for superior performance in commercial kitchens and ventilation systems. Designed with non-overloading backward inclined (BI) welded wheels, these blowers ensure efficient and reliable operation. The discharge position is field-rotatable to any of 8 positions, and both counterclockwise and clockwise rotations are available. Features include a vented motor and drive compartment cover for safety and weather protection, heavy-duty pillow block ball bearings, and a bolted clean-out door with a 2" drain for easy removal of cleaning solutions. Built with durable, 16-gauge welded housing, this model is ideal for the demanding conditions of restaurant environments.
FEATURES
- Non-overloading backward inclined (BI) welded wheels
- Discharge position can be field rotated to any of 8 discharge positions
- Counter clock wise rotation is standard. Clock wise available
- Motor access from 3 sides.
- Vented motor and drive compartment cover, with handles, for safety & weather protection
- 16 gauge or heavier blower housing
- Heavy duty pillow block ball bearings
- Continuously welded 16 gauge or heavier blower housing
- Bolted clean out door
- 2” drain for easy removal of cleaning solutions
- Complete range of sizes from 10” to 36”
- Vinyl shaft seal
Assembly Service Available
Thank you for your request. Our representative will call you as soon as possible.
| PART NUMBER | SHAFT SIZE | Max HP | CFM @ 1" SP | CFM @ 2" SP | UNIT SIZE (LxWxH) | ||
| BI-13RM | 1" | 5 | 3900 | 3625 | 34.25" x"x 30.94" |
|
|
| BI-16RM | 1 3/16" | 7.5 | 5700 | 5350 | 36.63" x"x 34.69" |
|
